Metallized Polyester Film Capacitors (MEF)
金属化ドポリプロピレンフィルムコンデンサ (MEF タイプ)


エポキシ樹脂塗装で高耐湿性
   Epoxy resin coating and high moisture resistance
無極性を持つ
   Non-inductive construction
自己回復性を持つ
  Self-healing characteristic
小型体積で軽量化
  Miniature size and light weight

 規格:
Rated Voltage
定格電圧 		100VDC ~ 630VDC
Capacitance Range
静電容量範囲 		0.01 ~ 4.7μF
Capacitance Tolerance
静電容量許容差 		J(±5%), K(±10%), M(±20%)
Dissipation Factor
誘電正接 		≤ 1% MAX at 1KHz and 20℃
Insulation Resistance
絶縁抵抗 		C ≤ 0.33μF, IR ≥ 30,000MΩ
C > 0.33μF, IR ≥ 10,000MΩ / μF
Dielectric Strength
耐電圧 		150% of rated voltage for 60sec
Operating Temperature
操作温度
 -40 ~ +85℃






　

　
