Safety Standard Recognized Ceramic Capacitors (Y1、Y2)
安規陶瓷電容  (Y1、Y2)


耐燃環氧樹脂成型塗裝 (UL94 V-0)
  Coated with flame-retardant epoxy resin (UL94 V-0)
適合自動插件
  Suitable for automatic insertion
安規認證
  Safety standard recognized for AC applications


Y1 Y2
Rated Voltage
額定電壓 		250VAC
Capacitance Range
電容量範圍 		100pF to 4700pF 100pF to 10000pF
Operating Temperature
操作溫度 		-25℃ to 125℃
Dielectric Withstanding Voltage
耐電壓 		4000VAC for 1 minute 2600VAC for 1 minute
Capacitance
容量 		Within the specified tolerance when measured at 1KHz±20%(Y5P, Y5U, Y5V, X7R), 1MHz ±20%(COG), 1Vrms and 25℃
Dissipation Factor Dissipation Factor(tanδ)
損耗因素 		tanδ ≤ 2.5% for char. Y5P, Y5U, Y5V, X7R when measured at 1KHz±20% 1Vrms and 25℃ Quality Factor ≥ 300 for char. COG when measured at 1MHz±20% 1Vrms and 25℃
Insulation Resistance(IR)
絕緣阻抗 		10,000 MΩ min. at 500VDC

Capacitance(pF)
電容量範圍(pF) 		Y1 Y2
100
150
200
330
470
560
680
1000
1500
2200
3300
4700
10000





　

　
