High
Resistor (RMC
Series) | | |
FEATURES¡G
 Resistance value range is 10K~100M£[.
Stable and long service life
UL1676 Authentication scope 100K ~ 100M (File
No.E220321)
|
|
|
ITEM |
SPEC |
REMARKS |
|
Load life under high temperature
|
¡Ó5% |
JIS C 5201-1¡@¡@Rated voltage at 70¢J for 1,000 hours
(4.25.1)¡@ ¡@¡@¡@ |
|
Load life under high humidity
|
¡Ó5% |
JIS C 5201-1¡@¡@Rated voltage at 40¢J,95% RH for 1,000
hours
(4.24)¡@¡@ ¡@¡@¡@ |
|
Temp. coeff. of resistance
|
¡Ó350 PPM/¢J |
JIS C 5201-1¡@¡@Room temp. + 100¢J¡A30min
¡@¡@¡@¡@¡@¡@¡@¡@ |
|
Short time overload
|
¡Ó1% |
JIS C 5201-1¡@¡@6.25 times the rated power for 5 seconds
(4.13)¡@¡@¡@¡@¡@ |
|
Temperature cycling
|
¡Ó1% |
JIS C 5201-1¡@5 cycles for ¡V25¢J¡Ó3¢J(30min)¡Froom
temp.(30min)
(4.19)¡@¡@¡@¡@ ~ +85¢J¡Ó3¢J(30min) room temp. (30min) |
|
Resistance to soldering heat |
¡Ó1% |
JIS C 5201-1¡@¡@260¢J¡Ó5¢J for 10 seconds
(4.18)¡@¡@¡@¡@¡@ 350¢J¡Ó10¢J for 3.5 seconds |
|
Insulation resistance
|
>1,000M£[ |
JIS C 5201-1¡@¡@500 volt Insulation test 1min
(4.6.1.1)¡@¡@¡@¡@ |
|
Pulse withstanding voltage
|
¡Ó20%
|
|
|
¡½The following discharge cycle is repeated in the
circuit of the left fig. 2.5 sec. ON 2.5 sec. OFF 50
cycles.
With following DC pulse test voltage
¡½
Pulse voltage: <100K£[¡G5KV
¡Ù100K£[¡G10KV | |
 |
|
| Various type of forming & taping are
available |
| |
| Coating color¡G1/4W Green, S1/2W
Pale-green,¡B¡Ù1/2W Gray |
| | |
|
Model |
Power
Rating
(W) |
Resistance
Range E-24
£[ |
Maximum
Working
Voltage |
Max Overload |
Dielectric
Withstanding
Voltage |
Dimension (mm) |
|
L |
D £p |
£d |
d £p |
|
1/4W¡B1/2W(S) |
1/4, 1/2 |
10K ~ <100M |
1600V |
1600V |
500V |
6¡Ó0.3 |
2.4¡Ó0.1 |
28¡Ó2 |
0.6¡Ó0.05 |
| 1/2W, 1W(S) |
1/4,1/2 |
10K ~ <100M |
2000V |
2000V |
700V |
9¡Ó0.5 |
3.3¡Ó0.5 |
30¡Ó3 |
0.6¡Ó0.05 |
| 1W, 2W(S) |
1/2,1 |
10K ~ <100M |
3500V |
3500V |
700V |
12  |
4.5¡Ó0.5 |
38¡Ó3 |
0.8¡Ó0.05 |
| 2W, 3W(S) |
1,2 |
10K ~ <100M |
3500V |
3500V |
700V |
16 |
5.5¡Ó0.5 |
38¡Ó3 |
0.8¡Ó0.05 |
| UL1676 Conductive-path (File
No.E220321) |
...............................................................................................................................................................................................................................................
|
