ITEM 項 目
|
SPEC. 規 格
|
REMARKS 備 註
|
|
Load life under high temperature
高溫負荷壽命
|
±1.5%
|
JIS C 5201-1 Rated voltage at 70℃ for 1000 hours
(4.25.1) 額定電壓70℃ 1000 小時
|
|
High humidity load life
高濕負荷壽命
|
±5%
|
JIS C 5201-1 Rated voltage at 400C,95% RH for
1000 hours
(4.24) 額定電壓40℃,95% RH 1000 小時
|
|
Temp. coeff. of resistance
溫度係數
|
±200 ppm/℃
|
JIS C 5201-1 Room temp. + 100℃
室溫 + 100℃
|
|
Short time overload
短時間過負荷
|
± 1%
|
JIS C 5201-1 6.25 times the rated power for 5
seconds
(4.13) 6.25倍額定功率 5 秒
|
|
Temperature cycling
溫度循環
|
±1%
|
JIS C 5201-1 5 cycles for –25℃±3℃(30min)；room
(4.19) temp.(30min)~ +85℃±3℃(30min) room temp.(30min)
|
|
Resistance to soldering heat
焊錫耐熱
|
±1%
|
JIS C 5201-1 260℃±5 ℃ for 10 seconds(焊錫槽)
(4.18) 350℃±10 ℃ for 3.5 seconds(手焊錫)
|
|
Insulation resistance
絕緣電阻
|
≧50G
|
JIS C 5201-1 500 V Insulation test 1min
(4.6.1.1) 500 V絕緣測試電壓1min
|
|
UL Pulse withstanding voltage
UL脈衝試驗
|
±20%
|
 |
■The following discharge cycle is repeated
in the circuit of the left fig. 2.5 sec. ON 2.5 sec. OFF 50 cycles.
Test voltage (DC source) 10KV(Max) |
|
|
Withstanding voltage
脈衝試驗
|
±3%
|
|
|
■The following discharge cycle is repeated
in the circuit of the left fig. 1 sec. ON 1 sec. OFF 50 cycles. Test
voltage (DC source) is shown below:
■Pulse voltage
1/4W＝（＞8.5KV,Max＝13KV）
 1/2W＝（＞14KV,Max＝20KV） |
|
Resistance value range is 680K~3G.
